Lenze i55AE155F

Parameter Name / value range / [default seng] Info
0x2860:003
(P201.03)
Torque control: Default setpoint source
(Stnd. setpoints: Torque setp.src.)
•
From version 03.00
Selecon of the standard setpoint source for operang mode "MS: Tor-
que mode".
•
The selected standard setpoint source is always acve in the operat-
ing mode 0x6060 (P301.00) = "MS: Torque mode [-1]" when no set-
point change-over to another setpoint source via corresponding trig-
gers/funcons is acve.
1 Keypad The setpoint is specied locally by the keypad.
•
Default seng: 0x2601:003 (P202.03)
•
Use the and navigaon keys to change the keypad setpoint
(also during running operaon).
2 Analog input 1 The setpoint is dened as analog signal via the analog input 1.
4Analog input 1 ^ 597
3 Analog input 2 The setpoint is dened as analog signal via the analog input 2.
4Analog input 2 ^ 601
4 HTL input (from version 04.00) The digital inputs DI3 and DI4 can be congured as HTL input to use an
HTL encoder as setpoint encoder or dene the setpoint as a reference
frequency ("pulse train").
4HTL input setpoint source ^ 565
5 Network The setpoint is dened as process data object via the network.
4Conguring the network ^ 226
11 Torque preset 1 For the setpoint selecon, preset values can be parameterised and selec-
ted.
4Setpoint source of preset setpoints ^ 554
12 Torque preset 2
13 Torque preset 3
14 Torque preset 4
15 Torque preset 5
16 Torque preset 6
17 Torque preset 7
18 Torque preset 8
31 Segment preset 1 For the setpoint selecon, the segment presets parameterised for the
"sequencer" funcon can be selected as well.
4Sequencer ^ 504
32 Segment preset 2
33 Segment preset 3
34 Segment preset 4
35 Segment preset 5
36 Segment preset 6
37 Segment preset 7
38 Segment preset 8
50 Motor potenometer The setpoint is generated by the "motor potenometer" funcon. This
funcon can be used as an alternave setpoint control which is control-
led via two signals: "MOP setpoint up" and "MOP setpoint down".
4Motor potenometer setpoint source (MOP) ^ 559
201 Internal value (from version 05.00) Internal values of the manufacturer.
202 Internal value (from version 05.00)
203 Internal value (from version 05.00)
204 Internal value (from version 05.00)
205 Internal value (from version 05.00)
206 Internal value (from version 05.00)
7.4.1 Keypad setpoint default seng
For the manual setpoint selecon via keypad the following default sengs are used.
Parameter Name / value range / [default seng] Info
0x2601:001
(P202.01)
Keypad setpoints: Frequency setpoint
(Keypad setpoints: KP freq.setpoint)
0.0 ... [20.0] ... 599.0 Hz
Default seng of the keypad setpoint for the operang mode 0x6060
(P301.00) = "MS: Velocity mode [-2]".
0x2601:002
(P202.02)
Keypad setpoints: Process controller setpoint
(Keypad setpoints: KP PID setpoint)
-300.00 ... [0.00] ... 300.00 PID unit
Default seng of the keypad setpoint for the reference value of the PID
control.
Basic seng
Selecon of setpoint source
Keypad setpoint default seng
151
