Lenze i55AE155F

Parameter Name / value range / [default seng] Info
0x23A4:002
(P512.02)
Port sengs: Port 2
(Port sengs: Port 2)
•
From version 02.00
Set baud rate for Ethernet port 2.
0 Auto-Negoaon
1 10 Mbps
2 100 Mbps
3 Reserved
4 Reserved
5 10 Mbps/Half Duplex
6 10 Mbps/Full Duplex
7 100 Mbps/Half Duplex
8 100 Mbps/Full Duplex
9 Reserved
10 Reserved
11 Reserved
12 Reserved
0x23A7
(P514.00)
Address conict detecon
(AddrConctDetec)
•
From version 02.00
Acvate address conict detecon (ACD) (enable).
•
If this value is changed, the device must be reset ("Power o/on" or
"Type 0 Reset").
0 Disabled
1 Enabled
0x23A3
(P509.00)
EtherNet/IP switch posion
(EtherN. switch)
•
Read only
•
From version 02.00
Display of the rotary encoder switch sengs at the last mains power-on.
0x23A6
(P513.00)
Quality of service
(QualityOfService)
•
Read only
•
From version 02.00
Display if the QoS tag for priorising the data packages to be transmied
is used.
0 802.1Q Tag disable
1 802.1Q Tag enable
9.7.2 Monitoring
The parameters for seng network monitoring funcons are described below.
Parameter Name / value range / [default seng] Info
0x23A1:010
(P510.10)
EtherNet/IP sengs: Timeout
(EtherN/IP se.: Timeout)
500 ... [10000] ... 65535 ms
•
From version 02.00
Seng of the maximum permissible me-out for the CIP communica-
on.
When the specied monitoring me has elapsed, the response set in
0x2859:007 (P515.07) is triggered in the inverter.
0x2859:001
(P515.01)
EtherNet/IP monitoring: Watchdog elapsed
(EtherN/IP monit.: WD elapsed)
•
From version 02.00
•
For further possible sengs, see parameter
0x2D45:001 (P310.01). ^ 223
Selecon of the response to a permanent interrupon of the communi-
caon to the Scanner, e. g. by cable break or failure of the Scanner.
Associated error code:
•
33168 | 0x8190 - Network: watchdog meout
2 Trouble
0x2859:003
(P515.03)
EtherNet/IP monitoring: Invalid conguraon
(EtherN/IP monit.: Invalid cong)
•
From version 02.00
•
For further possible sengs, see parameter
0x2D45:001 (P310.01). ^ 223
Selecon of the response triggered by the recepon of invalid congura-
on data.
Associated error code:
•
33414 | 0x8286 - Network: PDO mapping error
2 Trouble
0x2859:004
(P515.04)
EtherNet/IP monitoring: Inialisaon error
(EtherN/IP monit.: Init. error)
•
From version 02.00
•
For further possible sengs, see parameter
0x2D45:001 (P310.01). ^ 223
Selecon of the response triggered by the occurrence of an error during
the inialisaon of the network component.
Associated error code:
•
33170 | 0x8192 - Network: inialisaon error
2 Trouble
Conguring the network
EtherNet/IP
Basic sengs
320
