Lenze i55AE155F

Parameter Name / value range / [default seng] Info
0x263A:003
(P441.03)
Analog output 2: Min. signal
(Analog output 2: AO2 min. signal)
-2147483648 ... [0] ... 2147483647
•
Only available for applicaon I/O.
Denion of the signal value that corresponds to the minimum value at
analog output 2.
Example: conguraon of analog output 1 as a 4 ... 20 mA current loop:
output current 4 mA ≡ 0x263A:003
0x263A:004
(P441.04)
Analog output 2: Max. signal
(Analog output 2: AO2 max. signal)
-2147483648 ... [1000] ... 2147483647
•
Only available for applicaon I/O.
Denion of the signal value that corresponds to the maximum value at
analog output 2.
Example: conguraon of analog output 1 as a 4 ... 20 mA current loop:
output current 20 mA ≡ 0x263A:004
0x4008:003
(P590.03)
Process input words: NetWordIN3
(NetWordINx: NetWordIN3)
0.0 ... [0.0] ... 100.0 %
Mappable data word for oponal control of an analog output via net-
work.
Assignment of the analog outputs:
•
Analog output 1: 0x2639:002 (P440.02) = "NetWordIN3 [20]"
•
Analog output 2: 0x263A:002 (P441.02) = "NetWordIN3 [20]"
0x4008:004
(P590.04)
Process input words: NetWordIN4
(NetWordINx: NetWordIN4)
0.0 ... [0.0] ... 100.0 %
Mappable data word for oponal control of an analog output via net-
work.
Assignment of the analog outputs:
•
Analog output 1: 0x2639:002 (P440.02) = "NetWordIN4 [21]"
•
Analog output 2: 0x263A:002 (P441.02) = "NetWordIN4 [21]"
Flexible I/O conguraon
Conguraon of analog outputs
Analog output 2
621
