Lenze i55AE155F

14.13 Conguraon of digital inputs
Sengs for digital inputs 1 ... 7.
Precondions
Digital input 6 and digital input 7 are only available for a Control Unit (CU) with applicaon
I/O.
Details
The digital inputs are used for control tasks. For this purpose, the digital inputs are available as
selectable triggers for funcons.
The following sengs are possible for the digital inputs:
•
Asseron level "HIGH acve" or "LOW acve"
①
•
Debounce me
②
•
Inversion
③
Trigger
DI1
1
0
1
0x2632 001:
0 t
DI2
0 t
DI3
0 t
0x2633 001:
0x2632 002:0x2633 002:
0x2632 003:0x2633 003:
0x2630:001
1
0
1
1
0
1
DI4
0 t
0x2632 004:0x2633 004:
1
0
1
DI5
0 t
0x2632 005:0x2633 005:
1
0
1
X3
DI6
0 t
0x2632 006:0x2633 006:
1
0
1
DI7
0 t
0x2632 007:0x2633 007:
1
0
1
0x60FD - Bit 16
0x60FD - Bit 17
0x60FD - Bit 18
0x60FD - Bit 19
0x60FD - Bit 20
0x60FD - Bit 21
0x60FD - Bit 22
0x60FD - Bit 25
Digital input 7 [17]
Digital input 6 [16]
Digital input 5 [15]
Digital input 4 [14]
Digital input 3 [13]
Digital input 2 [12]
Digital input 1 [11]
HIGH-active / LOW-active
Diagnosc parameters:
•
The logic status of the digital inputs is displayed in 0x60FD (P118.00).
Flexible I/O conguraon
Conguraon of digital inputs
