9.9.5 Monitoring
The parameters for seng network monitoring funcons are described below.
Parameter Name / value range / [default seng] Info
0x2859:001
(P515.01)
PROFINET monitoring: Watchdog elapsed
(PROFINET monit.: WD elapsed)
•
From version 02.00
•
For further possible sengs, see parameter
0x2D45:001 (P310.01). ^ 223
Selecon of the response to a permanent interrupon of the communi-
caon to the IO controller.
Associated error code:
•
33168 | 0x8190 - Network: watchdog meout
2 Trouble
0x2859:002
(P515.02)
PROFINET monitoring: Data exchange exited
(PROFINET monit.: Data exch.exited)
•
For further possible sengs, see parameter
0x2D45:001 (P310.01). ^ 223
0 No response
0x2859:003
(P515.03)
PROFINET monitoring: Invalid conguraon
(PROFINET monit.: Invalid cong)
•
From version 02.00
•
For further possible sengs, see parameter
0x2D45:001 (P310.01). ^ 223
Selecon of the response triggered by the recepon of invalid congura-
on data.
Associated error code:
•
33414 | 0x8286 - Network: PDO mapping error
2 Trouble
0x2859:004
(P515.04)
PROFINET monitoring: Inialisaon error
(PROFINET monit.: Init. error)
•
From version 02.00
•
For further possible sengs, see parameter
0x2D45:001 (P310.01). ^ 223
Selecon of the response triggered by the occurrence of an error during
the inialisaon of the network component.
Associated error code:
•
33170 | 0x8192 - Network: inialisaon error
2 Trouble
0x2859:005
(P515.05)
PROFINET monitoring: Invalid process data
(PROFINET monit.: Inval. proc.data)
•
From version 02.00
•
For further possible sengs, see parameter
0x2D45:001 (P310.01). ^ 223
Selecon of the response triggered by the recepon of invalid process
data.
Process data marked as invalid (IOPS is "BAD") are received by the IO
Controller. Typically in case of
•
a PLC in STOP state,
•
alarms,
•
acyclic demand data.
Associated error code:
•
33171 | 0x8193 - Network: invalid cyclic process data
2 Trouble
