16.1.2.2 Funcon of the keypad keys in the parameterisaon mode
In the parameterisaon mode, the arrow keys serve to select and change parameters.
Funcon of the keypad keys in the parameterisaon mode
Key Actuaon Condion Acon
Shortly Local keypad control acve.
Display "LOC"
Run motor.
Remote control acve
Display "REM"
Display "KSTOP"
Deacvate keypad triggered stop.
The motor remains at standsll.
Display changes from "KSTOP" to "STOP".
Shortly No Jog operaon Stop motor.
Display "KSTOP"
Shortly Parameterisaon mode Navigate to one level below.
Group level à Parameter level à [SUB parameter level] à
Eding mode
Eding mode Exit eding mode and accept new seng.
More than 3 s None (anyme possible) Save parameter sengs in the user memory of the memory
module.
Shortly Parameterisaon mode Navigate to one level above.
[SUB parameter level] à Parameter level à Group level à
Operang mode
Eding mode Abort: Exit eding mode without accepng new seng.
Shortly Group level/Parameter level Navigate: Select group/parameter.
Eding mode Change parameter seng.
CTRL
Without funcon
R
F
Without funcon
