Lenze i55AE155F

9.7.5 Objects
An EtherNet/IP node is a collecon of objects. A single object is described by its class, their
instances and aributes. Various services such as read or write services can be applied to
these objects.
This chapter only describes the CIP objects implemented by Lenze and their sup-
ported features (aributes).
Not all object features as described in the "Common Industrial Protocol Speci-
caon" of the ODVA are supported.
Class Aribute Services
These "Class Aribute Services" are supported:
Service ID Name Data type
1 Get Revision UNIT
2 Get Max. Instance
3 Get Number of Instances
4 Get Number Aributes
5 Get Oponal Aributes
6 Get Max. ID Number Class Aributes
7 Get Max. ID Number Instance Aributes
Instance Aribute Services
These "Instance Aribute Services" are supported:
Service ID Name Data type
1 Get No. of Member in List UNIT
2 Get Member List
3 Get/Set Data
4 Get Size
0x01: Identy Object
The "Identy Object" provides the idencaon and the general informaon on the device.
Aribute
(Instance ID)
Name Info
1 Vendor ID Lenze
2 Device Type 2 (AC Drive)
3 Product Code 550
4 Revision e.g. "1.5"
5 Status
6 Serial Number
7 Product Name IOFW51AGXX
8 State
Conguring the network
EtherNet/IP
Objects
324
