Lenze i55AE155F

Parameter Name / value range / [default seng] Info
0x23A2:003
(P511.03)
Acve EtherNet/IP sengs: Gateway
(EtherN/IP diag.: Gateway)
•
Read only
•
From version 02.00
Display of the acve gateway address.
Example:
The seng 276344004 corresponds to the gateway address
196.172.120.16.
•
276344004 = 0x1078ACC4 à 0xC4.0xAC.0x78.0x10 = 196.172.120.16
0x23A2:005
(P511.05)
Acve EtherNet/IP sengs: MAC address
(EtherN/IP diag.: MAC address)
•
Read only
•
From version 02.00
Display of the acve MAC address.
0x23A2:006
(P511.06)
Acve EtherNet/IP sengs: Mulcast address
(EtherN/IP diag.: Mcast address)
•
Read only
•
From version 02.00
Display of the acve Mulcast IP address.
The default seng 3221373167 corresponds to the Mulcast IP address
239.64.2.192.
•
3221373167 = 0xC00240EF à 0xEF.0x40.0x02.0xC0 = 239.64.2.192
0x23A5:001
(P519.01)
Acve port sengs: Port 1
(Port diagnoscs: Port 1)
•
Read only
•
From version 02.00
Display of the acve baud rate for Ethernet port 1.
0 Not connected
1 10 Mbps/Half Duplex
2 10 Mbps/Full Duplex
3 100 Mbps/Half Duplex
4 100 Mbps/Full Duplex
0x23A5:002
(P519.02)
Acve port sengs: Port 2
(Port diagnoscs: Port 2)
•
Read only
•
From version 02.00
Display of the acve baud rate for Ethernet port 2.
0 Not connected
1 10 Mbps/Half Duplex
2 10 Mbps/Full Duplex
3 100 Mbps/Half Duplex
4 100 Mbps/Full Duplex
5 Reserved
6 Reserved
0x23A8
(P516.00)
CIP module status
(CIP module stat.)
•
Read only
•
From version 02.00
Display of the acve CIP module status.
0x23A9
(P517.00)
EtherNet/IP status
(EtherN/IP status)
•
Read only
•
From version 02.00
Display of the acve network status.
Conguring the network
EtherNet/IP
Diagnoscs
323
