5.3.1 General notes on parameters
Each parameter features a 16-bit index as address. Under this address, the parameter is
stored in the object directory of the inverter.
•
Parameters that belong together funconally are combined in a data set. These parame-
ters are addionally provided with an 8-bit subindex.
•
The colon is used as a separator between the index and subindex Example: "0x2540:001"
•
There are parameters the seng of which can be changed, and (diagnosc) parameters
which can only be read.
Parameterisaon using the keypad
•
All parameters which can be accessed by means of the keypad are provided with a "Display
code", the rst digit of the display code specifying the group in which the parameter can
be found on the keypad.
•
In the documentaon, the display code — if available — is specied in brackets behind the
address. Example: "0x2915 (P210.00)".
4Keypad parameterisaon mode ^ 635
Structure of the parameter descripons in this documentaon
•
The parameter descripons in this documentaon are structured in table form.
•
The representaon disnguishes parameters with a seng range, text, selecon list, and
bit-coded display.
•
The default seng of parameters with a write access feature is shown in bold.
•
The display code as well as the short keypad designaon of the parameter which is limited
to 16 characters, are — if available — shown in brackets.
Example: parameters with a seng range
Parameter Name / value range / [default seng] Info
Index:Subindex
(display code)
Parameter designaon
(abbreviated keypad designaon)
Minimum value ... [default seng] ... maximum value
•
Oponal informaon with regard to the parameter.
Explanaons & notes with regard to the parameter.
Example: parameters with a selecon list
Parameter Name / value range / [default seng] Info
Index:Subindex
(display code)
Parameter designaon
(abbreviated keypad designaon)
•
Oponal informaon with regard to the parameter.
Explanaons & notes with regard to the parameter.
Note: The corresponding selecon number (here 0, 1, or 2) must be set.
Other values are not permissible.
0 Designaon of selecon 0 Oponally: Explanaons & notes with regard to the corresponding selec-
on.
The default selecon is shown in bold.
1 Designaon of selecon 1
2 Designaon of selecon 2
Example: parameters with a bit-coded display
Parameter Name / value range / [default seng] Info
Index:Subindex
(display code)
Parameter designaon
(abbreviated keypad designaon)
•
Oponal informaon with regard to the parameter.
Explanaons & notes with regard to the parameter.
Bit 0 Designaon of bit 0 Oponally: Explanaons & notes with regard to the corresponding bit.
Bit 1 Designaon of bit 1
Bit 2 Designaon of bit 2
... ...
Bit 15 Designaon of bit 15
Parameter overview lists in this documentaon
•
Keypad parameter list: for the parameterisaon using the keypad, contains a list of all
parameters which can also be accessed by means of the keypad. ^ 85
•
Parameter aribute list: contains a list of all inverter parameters. This list in parcular
includes some informaon that is relevant for the reading and wring of parameters via
the network. ^ 659
