15.5 3-phase mains connecon 400 V
15.5.1 Rated data
The output currents apply to these operang condions:
•
At a switching frequency of 2 kHz or 4 kHz: Max. ambient temperature 45°C.
•
At a switching frequency of 8 kHz or 16 kHz: Max. ambient temperature 40 °C.
Inverter I55AE137F I55AE155F I55AE175F I55AE211F I55AE215F I55AE222F I55AE230F
Rated power kW 0.37 0.55 0.75 1.1 1.5 2.2 3
Rated power hp 0.5 0.75 1 1.5 2 3 4
Mains voltage range 3/PE AC 340 V ... 528 V, 45 Hz ... 65 Hz
Output voltage 3 AC 0 V … 400 V
Rated mains current
without mains choke A 1.8 2.5 3.3 4.4 5.4 7.8 9.6
with mains choke A 1.4 2 2.6 3 3.7 5.3 6.9
Apparent output power kVA 0.9 1.2 1.6 2.2 2.6 3.8 4.9
Output current
2 kHz A - 1.8 2.4 3.2 3.9 5.6 7.3
4 kHz A 1.3 1.8 2.4 3.2 3.9 5.6 7.3
8 kHz A 1.3 1.8 2.4 3.2 3.9 5.6 7.3
16 kHz A 0.9 1.2 1.6 2.1 2.6 3.7 4.9
Weight kg 0.8 1 1.35 2.3
Weight lb 1.8 2.2 3 5
Inverter I55AE240F I55AE255F I55AE275F I55AE311F I55AE315F I55AE318F I55AE322F
Rated power kW 4 5.5 7.5 11 15 18.5 22
Rated power hp 5 7.5 10 15 20 25 30
Mains voltage range 3/PE AC 340 V ... 528 V, 45 Hz ... 65 Hz
Output voltage 3 AC 0 V … 400 V
Rated mains current
without mains choke A 12.5 17.2 20 28.4 38.7 48.4 -
with mains choke A 9 12.4 15.7 22.3 28.8 36 42
Apparent output power kVA 6.4 8.7 11 16 22 27 32
Output current
2 kHz A 9.5 13 16.5 23.5 32 40 47
4 kHz A 9.5 13 16.5 23.5 32 40 47
8 kHz A 9.5 13 16.5 23.5 32 40 47
16 kHz A 6.3 8.7 11 15.7 21.3 26.6 31.3
Weight kg 2.3 3.7 10.3
Weight lb 5 8 23
Technical data
3-phase mains connecon 400 V
Rated data
