Lenze i55AE155F

9.6.4 Baud rate seng
At the class 1 DP master, the desired baud rate is set. All masters at the bus must be set to the
same baud rate.
The parameters for the baud rate of the device are described below.
Details
•
The inverter detects the baud rate automacally.
•
The acve baud rate is displayed in 0x2342:002 (P511.02).
•
The status of automac detecon is displayed in 0x2348:002 (P516.02).
Parameter Name / value range / [default seng] Info
0x2342:002
(P511.02)
Acve PROFIBUS sengs: Acve baud rate
(PROFIBUS diag.: Acve baud rate)
•
Read only
Display of the acve baud rate.
0 12 Mbps
1 6 Mbps
2 3 Mbps
3 1.5 Mbps
4 500 kbps
5 187.5 kbps
6 93.75 kbps
7 45.45 kbps
8 19.2 kbps
9 9.6 kbps
15 Search Automac baud rate detecon acve.
0x2348:002
(P516.02)
PROFIBUS Status: Watchdog status
(PROFIBUS Status: Watchdog status)
•
Read only
Display of the current state of the watchdog state machine (WD-STATE).
0 BAUD_SEARCH The inverter (slave) is able to detect the baud rate automacally.
1 BAUD_CONTROL Aer detecng the correct baud rate, the inverter (slave) status changes
to BAUD_CONTROL, and the baud rate is monitored.
2 DP_CONTROL The DP_CONTROL state serves to the response monitoring of the master.
9.6.5 Monitoring
The inverter can give a parameterisable response to various PROFIBUS errors.
The parameters for seng network monitoring funcons are described below.
Details
The following table lists the PROFIBUS errors that can be set for a response.
Event Display in Response can be set in Default seng
Communicaon to the PROFIBUS master is connuously interrupted. 0x2349 (P517.00), Bit 0 0x2859:001 (P515.01) Error
Data exchange via PROFIBUS has been terminated. 0x2349 (P517.00), Bit 1 0x2859:002 (P515.02) No response
The inverter has received invalid conguraon data from the master. 0x2349 (P517.00), Bit 2 0x2859:003 (P515.03) Error
An error has occurred during the inialisaon of the PROFIBUS interface. 0x2349 (P517.00), Bit 3 0x2859:004 (P515.04) Error
The process data received are invalid. 0x2349 (P517.00), Bit 4 0x2859:005 (P515.05) Trouble
Parameter Name / value range / [default seng] Info
0x2342:003
(P511.03)
Acve PROFIBUS sengs: Watchdog me
(PROFIBUS diag.: Watchdog me)
•
Read only
Display of the watchdog monitoring me specied by the master.
•
Monitoring starts with the arrival of the rst telegram.
•
When a value of "0" is displayed, the monitoring funcon is deacva-
ted.
•
A change in the watchdog monitoring me in the master is eecve
immediately.
Conguring the network
PROFIBUS
Baud rate seng
296
