Lenze i55AE155F

4.4.5 EtherCAT
Typical topologies
Line
IN OUT
M
R
SDn
SD2
SD1
IN OUT IN
M Master
SD Slave Device
Basic network sengs
The rotary encoder switch allows you to set an EtherCAT idener.
x16 x1
Seng Idener
0x00 Value from parameter
0x01 ... 0xFF Switch posion
4.4.6 EtherNet/IP
Typical topologies
Line Tree
S
R
An
A2A1
S
SWn
SW2
SW1
Ring
S
An
A2
A1
A3
DLR
S Scanner SW Switch
A Adapter
Basic network sengs
The rotary encoder switch allows you to set the last byteof the IP address.
x16 x1
Seng Value of last byte Resulng IP address
0x00 Value from parameter Value from parameter
0x01 ... 0xFE Switch posion 192.168.124.<switch posion>
0xFF Default seng 192.168.124.16
Electrical installaon
Networks
EtherNet/IP
68
