14.15.5.2 Example 2: Pulse train 2 ... 10 kHz ≡ output frequency 30 ... 60 Hz
In this conguraon, the output range 2 ... 10 kHz is used for the output of the output fre-
quency (resoluon: 0.1 Hz). The example shows how the signals outside the signal range
(here: 30 ... 60 Hz) are cut o.
Parameter Designaon Seng for this example
0x2644:001 (P423.01) DO1 frequency setup: Minimum frequency 2000.0 Hz
0x2644:002 (P423.02) DO1 frequency setup: Maximum frequency 10000.0 Hz
0x2644:003 (P423.03) DO1 frequency setup: Funcon Output frequency [1]
0x2644:004 (P423.04) DO1 frequency setup: Minimum signal 300
0x2644:005 (P423.05) DO1 frequency setup: Maximum signal 600
0
10
[0.1 Hz]0
60.0
[Hz]30.0
DO1
X3
Hz
0x2644:003
Min
Max
2
600300
Pulse train [kHz]
Output frequency [1]
Flexible I/O conguraon
Conguraon of digital outputs
HTL output
