Lenze i55AE155F

16.1.1.2 Funcon of keypad keys in operang mode
In the operang mode, the keypad can be used for local control and for manual setpoint selec-
on.
Funcon of keypad keys in operang mode
Key Actuaon Condion Acon
Shortly Local keypad control acve.
Display "LOC"
Run motor.
Remote control acve
Display "REM"
Display "KSTOP"
Deacvate keypad triggered stop.
The motor remains at standsll.
Display changes from "KSTOP" to "STOP".
Shortly No Jog operaon Stop motor.
Display "KSTOP"
Shortly Operang mode Change to parameterisaon mode.
4Keypad parameterisaon mode ^ 635
More than 3 s None (anyme possible) Save parameter sengs in the user memory of the memory
module.
Shortly During operaon Scroll through informaon in the above status line.
Shortly Manual setpoint selecon via keypad
acve.
Display "MAN"
Change frequency setpoint.
CTRL
Shortly Operang mode Acvate full keypad control
Display "ON?" à Conrm with
Control and setpoint selecon can now only be carried out via
keypad.
Renewed clicking: Exit full keypad control.
Display "OFF?" à Conrm with
4Keypad - Conguraon of R/F and CTRL buons ^ 423
R
F
Shortly Local keypad control acve.
Display "LOC"
Reversal of rotaon direcon.
Display "REV?" à Conrm with
4Keypad - Conguraon of R/F and CTRL buons ^ 423
Example: Change setpoint
If the setpoints are selected manually via keypad, the frequency setpoint can be changed in
the operang mode via the arrow keys (even while the motor is running):
MAN AUTO SETLOC REM
VEL:KPD:KPD
0 0 0 S T O P
MAN AUTO SETLOC REM
P202.01 Hz
0 0 0 O 2 O O
MAN AUTO SETLOC REM
P202.01 Hz
0 0 0 O 3 5 6
Change settings
Editing mode is automatically quit after 3 s of inactivity
Editing modeOperating mode
Appendix
Operate and parameterise the inverter with keypad
Keypad operang mode
633
