9.9 PROFINET
PROFINET® (Process Field Network) is a real-me capable eldbus system based on Ethernet.
•
Detailed informaon on PROFINET can be found on the web page of the PROFIBUS & PRO-
FINET Internaonal (PI) user organisaon: hp://www.probus.com
•
Informaon about the dimensioning of a PROFINET network can be found in the congura-
on document for the inverter.
•
PROFINET® is a registered trademark and patented technology licensed by the PROFIBUS &
PROFINET Internaonal (PI) user organisaon.
Precondions
•
Control unit (CU) of the inverter is provided with PROFINET.
•
The required GSDML device descripon les for PROFINET are installed in the engineering
tool for conguring the network.
•
Download of GSDML les
9.9.1 Introducon
The inverter is implemented as IO-Device into a PROFINET network. PROFINET transmits
parameter data, conguraon data, diagnosc data, alarm messages and process data
between the IO-Devices and the IO-Controller (in the following, this term is used instead of
"PLC" or "host system").
The data is transmied as a funcon of its me-crical behaviour via corresponding communi-
caon channels.
Supported services
Features Inverter
Conformance Class CCB
Opon according to conformance class Media Redundancy Protocol
Device class IO device
According to PN specicaon V2.2
Safety channel support -
Shared device -
Device access TCI, I&M0 ... 4
Device prole support -
Conductor access OK
The second inverter Yes
Fast startup No. (typical starng mes, approx. 11 seconds)
Topology support LLDP MIB, staon alias
PN blinking funcon OK
Alarm type User
Acyclic services OK
Addional Ethernet channel TCP/IP channel
Lenze GCI support OK
Lenze ESDCP support OK
Power over Ethernet PoE -
External 24V current supply X3 24E / GND
Opcal ber support -
