Lenze i55AE155F

6.2.7 Setpoint diagnosc
The following parameters show the current setpoints of dierent setpoint sources.
Parameter Name / value range / [default seng] Info
0x282B:007 Inverter diagnoscs: Default frequency setpoint
•
Read only: x.x Hz
•
From version 03.00
Display of the frequency setpoint of the standard setpoint source set in
0x2860:001 (P201.01).
0x282B:008 Inverter diagnoscs: Preset frequency setpoint
•
Read only: x.x Hz
•
From version 03.00
Display of the preset frequency setpoint selected via the four funcons
"Acvate preset (bit 0)" ... " Acvate preset (bit 3)".
4Setpoint source of preset setpoints ^ 554
0x282B:009 Inverter diagnoscs: Actual frequency setpoint
•
Read only: x.x Hz
•
From version 03.00
Display of the currently selected frequency setpoint that is internally
transferred to the motor control.
0x282B:010 Inverter diagnoscs: Default PID setpoint
•
Read only: x.xx PID unit
•
From version 03.00
Display of the PID control value of the standard setpoint source set in
0x2860:002 (P201.02).
0x282B:011 Inverter diagnoscs: Preset PID setpoint
•
Read only: x.xx PID unit
•
From version 03.00
Display of the preset PID setpoint selected via the four funcons "Ac-
vate preset (bit 0)" ... " Acvate preset (bit 3)".
4Setpoint source of preset setpoints ^ 554
0x282B:012 Inverter diagnoscs: Default torque setpoint
•
Read only: x.x %
•
From version 03.00
Display of the torque setpoint of the standard setpoint source set in
0x2860:003 (P201.03).
•
100 % ≡ Motor rated torque 0x6076 (P325.00)
0x282B:013 Inverter diagnoscs: Preset torque setpoint
•
Read only: x.x %
•
From version 03.00
Display of the preset torque setpoint selected via the four funcons
"Acvate preset (bit 0)" ... " Acvate preset (bit 3)".
4Setpoint source of preset setpoints ^ 554
0x2948:001 Actual torque setpoint
•
Read only: x.x %
•
From version 03.00
Display of the currently selected torque setpoint that is internally trans-
ferred to the motor control.
•
100 % ≡ Motor rated torque 0x6076 (P325.00)
0x2DAE:010 Sequencer diagnoscs: Frequency setpoint
•
Read only: x.x Hz
•
From version 03.00
Display of the current frequency setpoint of the "sequencer" funcon.
4Sequencer ^ 504
0x2DAE:011 Sequencer diagnoscs: PID setpoint
•
Read only: x.xx PID unit
•
From version 03.00
Display of the current PID control value of the "sequencer" funcon.
4Sequencer ^ 504
0x2DAE:012 Sequencer diagnoscs: Torque setpoint
•
Read only: x.x %
•
From version 03.00
Display of the current torque setpoint of the "sequencer" funcon.
•
100 % ≡ Motor rated torque 0x6076 (P325.00)
4Sequencer ^ 504
0x4009:004 MOP values saved: Frequency setpoint
•
Read only: x.x Hz
Display of the last MOP value saved internally for the operang mode
"MS: Velocity mode".
0x4009:005 MOP values saved: PID setpoint
•
Read only: x.xx PID unit
Display of the last MOP value saved internally for the reference value of
the PID control.
0x4009:006 MOP values saved: Torque setpoint
•
Read only: x.x %
Display of the last MOP value saved internally for the operang mode
"MS: Torque mode".
Related topics
4Selecon of setpoint source ^ 148
4Setpoint change-over ^ 546
6.2.8 Process controller status
The following parameters serve to diagnose the process controller.
Parameter Name / value range / [default seng] Info
0x401F:001
(P121.01)
Current setpoint
(PID setpoint)
•
Read only: x.xx PID unit
Display of the current reference value (setpoint) for the process control-
ler.
0x401F:002
(P121.02)
Current process variable
(PID process var.)
•
Read only: x.xx PID unit
Display of the current controlled variable (actual value) fed back for the
process controller.
Diagnoscs and fault eliminaon
Diagnoscs parameter
Setpoint diagnosc
133
