Lenze i55AE155F

Parameter Name / value range / [default seng] Info
0x234A:005
(P580.05)
PROFIBUS stascs: C1 messages
(PROFIBUS counter: C1 messages)
•
Read only
Display of the number of requests by the class 1 DPV1 master.
0x234A:006
(P580.06)
PROFIBUS stascs: C2 messages
(PROFIBUS counter: C2 messages)
•
Read only
Display of the number of requests by the class 2 DPV1 master.
0x234A:007
(P580.07)
PROFIBUS stascs: Watchdog events
(PROFIBUS counter: WD events)
•
Read only
Display of the number of watchdog events.
0x234A:008
(P580.08)
PROFIBUS stascs: Data exchange aborts
(PROFIBUS counter: DataEx.event)
•
Read only
Display of the number of "Data Exchange exited" events.
0x234A:009
(P580.09)
PROFIBUS stascs: Total data cycles
(PROFIBUS counter: Tot. data cycles)
•
Read only
Display of the number of cyclic process data received.
0x2348:002
(P516.02)
PROFIBUS Status: Watchdog status
(PROFIBUS Status: Watchdog status)
•
Read only
Display of the current state of the watchdog state machine (WD-STATE).
0 BAUD_SEARCH The inverter (slave) is able to detect the baud rate automacally.
1 BAUD_CONTROL Aer detecng the correct baud rate, the inverter (slave) status changes
to BAUD_CONTROL, and the baud rate is monitored.
2 DP_CONTROL The DP_CONTROL state serves to the response monitoring of the master.
9.6.8 Funcons
The inverter supports PROFIBUS DP-V0 (DRIVECOM prole) and PROFIBUS DP-V1 (PROFIdrive
prole). PROFIBUS DP-V2 is not supported.
Details
The PROFIBUS DP communicaon protocol is provided with the following funcons:
•
DP-V0: cyclic data exchange, diagnoscs (all devices).
•
DP-V1: acyclic data exchange, process alarm processing (process automaon). Note: The
inverter does not support any alarm diagnoscs.
•
DP-V2: cycle synchronisaon and me stamp, slave-to-slave communicaon.
A class 1 DP master connecon (DPV1 C1) between a cyclic master and slave is established
automacally when the "Data Exchange" state has been established. In byte 7 of the parame-
terisaon frame, the "DPV1_Enable" bit must be set. Furthermore, a class 2 DP master con-
necon (DPV1 C2) with the slave can be dened by another master connected. This connec-
on must be established via the "MSAC2_Iniate" service.
The inverter supports the following acyclic DPV1 services:
•
MSAC1_Read/Write: C1 read/write request for a data block.
•
MSAC2_Iniate/Abort: connecon or disconnecon for acyclic data exchange between a
class 2 DP master and the slave.
•
MSAC2_Read/Write: C2 read/write request for a data block.
Conguring the network
PROFIBUS
Funcons
299
