9.9.3 LED status displays
Informaon on the network status can be obtained quickly via the "BUS RDY" and "BUS ERR"
LED displays on the front of the inverter. In addion, the LEDs at the RJ45 sockets indicate the
PROFINET connecon status.
The meaning of the "BUS RDY" and "BUS ERR" LEDs can be obtained from the following two
tables.
LED "BUS RDY" (green) Status/meaning
o No connecon to the master
blinking
PLC in STOP
on
PLC in RUN (DATA_EXCHANGE)
LED "BUS ERR" (red) Status/meaning
o No fault
ickers
The PROFINET funcon "Node ashing test" is triggered by the IO controller. The ickering LED serves to idenfy (locate)
accessible IO devices
blinking
Impermissible sengs: Stack, staon name or IP parameters are invalid.
on (red)
Communicaon error (e.g. Ethernet cable removed)
Status displays at the RJ45 sockets
The LEDs at the RJ45 sockets indicate the connecon status to the network:
LED "Link" (green) Status/meaning
o No connecon to the network.
on
A physical connecon to the network is available.
LED "Acvity" (yellow) Status/meaning
o No data transfer.
on or ickers
Data is exchanged via the network.
9.9.4 Diagnoscs
The parameters for diagnosing the network are described below.
Parameter Name / value range / [default seng] Info
0x2382:001
(P511.01)
Acve PROFINET sengs: IP address
(PROFINET diag.: IP address)
•
Read only
•
From version 02.00
Display of the acve IP address.
0x2382:002
(P511.02)
Acve PROFINET sengs: Subnet
(PROFINET diag.: Subnet)
•
Read only
•
From version 02.00
Display of the acve subnet mask.
0x2382:003
(P511.03)
Acve PROFINET sengs: Gateway
(PROFINET diag.: Gateway)
•
Read only
•
From version 02.00
Display of the gateway address.
0x2382:004
(P511.04)
Acve PROFINET sengs: Staon name
(PROFINET diag.: Staon name)
•
Read only
•
From version 02.00
Display of the acve staon name.
0x2382:005
(P511.05)
Acve PROFINET sengs: MAC Address
(PROFINET diag.: MAC Address)
•
Read only
•
From version 02.00
Display of the acve MAC address.
