Lenze i55AE155F

4.3 Control connecons
Terminal descripon Relay output PTC input Control terminals
Connecon X9 X109 X3
Connecon type pluggable screw terminal pluggable screw terminal pluggable spring terminal
Min. cable cross-secon mm² 0.5 0.5 0.5
Min. cable cross-secon AWG 22 22 22
Max. cable cross-secon mm² 1.5 1.5 1.5
Max. cable cross-secon AWG 14 14 16
Stripping length mm 6 6 9
Stripping length inch 0.24 0.24 0.35
Tightening torque Nm 0.2 0.2 -
Tightening torque lb-in 1.8 1.8 -
Required tool 0.4 x 2.5 0.4 x 2.5 0.4 x 2.5
Electrical installaon
Control connecons
63
