Lenze i55AE155F

Parameter Name / value range / [default seng] Info
0x401F:003
(P121.03)
Status
(PID status)
•
Read only
Bit-coded status display of the process controller.
Bit 0 Process controller o
Bit 1 PID output set to 0
Bit 2 PID I-component inhibited
Bit 3 PID inuence acve
Bit 4 Setpoint = actual value
Bit 5 Idle state acve
Bit 6 Max. alarm
Bit 7 Min. alarm
0x401F:004 PID control value
•
Read only: x.x Hz
•
From version 03.00
Display of the output frequency aer the PID controller, but without any
inuencing factor.
0x401F:005 PID Feedforward value
•
Read only: x.x Hz
•
From version 03.00
Display of the feedforward control value for the process controller.
0x401F:006 PID output value
•
Read only: x.x Hz
•
From version 03.00
Display of the current process controller setpoint that is internally trans-
ferred to the motor control (considering the feedforward control value).
0x401F:007 PID error value
•
Read only: x.xx PID unit
•
From version 03.00
Display of the dierence between reference value (setpoint) and fed
back variable (actual value) of the process controller.
Related topics
4Conguring the process controller ^ 407
6.2.9 Sequencer diagnoscs
The following parameters serve to diagnose the "sequencer" funcon.
Parameter Name / value range / [default seng] Info
0x2DAE:001
(P140.01)
Sequencer diagnoscs: Acve step
(Sequencer diag: Acve Step)
•
Read only
•
From version 03.00
Display of the acve step.
•
0 ≡ no sequence acve.
0x2DAE:002
(P140.02)
Sequencer diagnoscs: Step me elapsed
(Sequencer diag: StepTime elapsed)
•
Read only: x.x s
•
From version 03.00
Display of the me that has passed since the start of the current step.
0x2DAE:003
(P140.03)
Sequencer diagnoscs: Step me remaining
(Sequencer diag: StepTime remain)
•
Read only: x.x s
•
From version 03.00
Display of the residual me for the current step.
0x2DAE:004
(P140.04)
Sequencer diagnoscs: Steps complete
(Sequencer diag: Steps complete)
•
Read only
•
From version 03.00
Display of the number of steps that have been made since the start of
the sequence.
0x2DAE:005
(P140.05)
Sequencer diagnoscs: Steps remaining
(Sequencer diag: Steps remain)
•
Read only
•
From version 03.00
Display of the residual number of steps unl the current sequence is
completed. This includes the current step.
0x2DAE:006
(P140.06)
Sequencer diagnoscs: Acve sequence
(Sequencer diag: Acve sequence)
•
Read only
•
From version 03.00
Display of the acve sequence.
•
0 ≡ no sequence acve.
0x2DAE:007
(P140.07)
Sequencer diagnoscs: Acve segment
(Sequencer diag: Acve segment)
•
Read only
•
From version 03.00
Display of the acve segment.
•
0 ≡ no sequence acve.
•
255 ≡ nal sequence acve.
Diagnoscs and fault eliminaon
Diagnoscs parameter
Process controller status
134
