15.2 1-phase mains connecon 120 V
15.2.1 Rated data
The output currents apply to these operang condions:
•
At a switching frequency of 2 kHz or 4 kHz: Max. ambient temperature 45°C.
•
At a switching frequency of 8 kHz or 16 kHz: Max. ambient temperature 40 °C.
Inverter I55AE125A I55AE137A I55AE175A I55AE211A
Rated power kW 0.25 0.37 0.75 1.1
Rated power hp 0.33 0.5 1 1.5
Mains voltage range 1/N/PE AC 90 V ... 132 V, 45 Hz ... 65 Hz
Output voltage 3 AC 0 V … 240 V
Rated mains current
without mains choke A 6.8 9.6 16.8 22.9
with mains choke A 6 8.5 14.7 17.1
Apparent output power kVA 0.6 0.9 1.6 2.2
Output current
2 kHz A 1.7 2.4 4.2 6
4 kHz A 1.7 2.4 4.2 6
8 kHz A 1.7 2.4 4.2 6
16 kHz A 1.1 1.6 2.8 4
Weight kg 1 1.35
Weight lb 2.2 3
Technical data
1-phase mains connecon 120 V
Rated data
624
