Address Designaon Default seng Category Data type Factor A M
0x2631:006
(P400.06)
Funcon list: Start forward (CW) Not connected [0] general U8 1 PC -
0x2631:007
(P400.07)
Funcon list: Start reverse (CCW) Not connected [0] general U8 1 PC -
0x2631:008
(P400.08)
Funcon list: Run forward (CW) Not connected [0] general U8 1 PC -
0x2631:009
(P400.09)
Funcon list: Run reverse (CCW) Not connected [0] general U8 1 PC -
0x2631:010
(P400.10)
Funcon list: Jog foward (CW) Not connected [0] general U8 1 PC -
0x2631:011
(P400.11)
Funcon list: Jog reverse (CCW) Not connected [0] general U8 1 PC -
0x2631:012
(P400.12)
Funcon list: Acvate keypad control Not connected [0] general U8 1 P -
0x2631:013
(P400.13)
Funcon list: Reverse rotaonal direcon Digital input 3 [13] general U8 1 PC -
0x2631:014
(P400.14)
Funcon list: Acvate AI1 setpoint Not connected [0] general U8 1 P -
0x2631:015
(P400.15)
Funcon list: Acvate AI2 setpoint Not connected [0] general U8 1 P -
0x2631:016
(P400.16)
Funcon list: Acvate keypad setpoint Not connected [0] general U8 1 P -
0x2631:017
(P400.17)
Funcon list: Acvate network setpoint Not connected [0] general U8 1 P -
0x2631:018
(P400.18)
Funcon list: Acvate preset (bit 0) Digital input 4 [14] general U8 1 P -
0x2631:019
(P400.19)
Funcon list: Acvate preset (bit 1) Digital input 5 [15] general U8 1 P -
0x2631:020
(P400.20)
Funcon list: Acvate preset (bit 2) Not connected [0] general U8 1 P -
0x2631:021
(P400.21)
Funcon list: Acvate preset (bit 3) Not connected [0] general U8 1 P -
0x2631:022
(P400.22)
Funcon list: Acvate setpoint via HTL input Not connected [0] general U8 1 P -
0x2631:023
(P400.23)
Funcon list: MOP setpoint up Not connected [0] general U8 1 P -
0x2631:024
(P400.24)
Funcon list: MOP setpoint down Not connected [0] general U8 1 P -
0x2631:025
(P400.25)
Funcon list: Acvate MOP setpoint Not connected [0] general U8 1 P -
0x2631:026
(P400.26)
Funcon list: Acvate segment setpoint (bit 0) Not connected [0] general U8 1 P -
0x2631:027
(P400.27)
Funcon list: Acvate segment setpoint (bit 1) Not connected [0] general U8 1 P -
0x2631:028
(P400.28)
Funcon list: Acvate segment setpoint (bit 2) Not connected [0] general U8 1 P -
0x2631:029
(P400.29)
Funcon list: Acvate segment setpoint´(bit 3) Not connected [0] general U8 1 P -
0x2631:030
(P400.30)
Funcon list: Run/abort sequence Not connected [0] general U8 1 PC -
0x2631:031
(P400.31)
Funcon list: Start sequence Not connected [0] general U8 1 PC -
0x2631:032
(P400.32)
Funcon list: Next sequence step Not connected [0] general U8 1 PC -
0x2631:033
(P400.33)
Funcon list: Pause sequence Not connected [0] general U8 1 PC -
0x2631:034
(P400.34)
Funcon list: Suspend sequence Not connected [0] general U8 1 PC -
* Default seng depending on the size. Firmware version 05.00.00.00
