Address Designaon Default seng Category Data type Factor A M
0x2644:003
(P423.03)
DO1 frequency setup: Funcon Not connected [0] general U8 1 P -
0x2644:004
(P423.04)
DO1 frequency setup: Minimum signal 0 general I32 1 P -
0x2644:005
(P423.05)
DO1 frequency setup: Maximum signal 1000 general I32 1 P -
0x2645:001
(P424.01)
DO2 frequency setup: Minimum frequency 0.0 Hz general I32 10 -
0x2645:002
(P424.02)
DO2 frequency setup: Maximum frequency 10000.0 Hz general I32 10 -
0x2645:003
(P424.03)
DO2 frequency setup: Funcon Not connected [0] general U8 1 -
0x2645:004
(P424.04)
DO2 frequency setup: Minimum signal 0 general I32 1 -
0x2645:005
(P424.05)
DO2 frequency setup: Maximum signal 1000 general I32 1 -
0x2646:001
(P114.01)
DO actual frequency: Digital output 1 x.x Hz (Read only) general I32 10 - t
0x2646:002
(P114.02)
DO actual frequency: Digital output 2 x.x Hz (Read only) general I32 10 - t
0x2820:001
(P712.01)
Holding brake control: Brake mode O [2] general U8 1 P r
0x2820:002
(P712.02)
Holding brake control: Brake closing me 100 ms general U16 1 P -
0x2820:003
(P712.03)
Holding brake control: Brake opening me 100 ms general U16 1 P -
0x2820:007
(P712.07)
Holding brake control: Brake closing threshold 0.2 Hz general U16 10 P -
0x2820:008
(P712.08)
Holding brake control: Brake holding load 0.0 % general I16 10 P -
0x2820:012
(P712.12)
Holding brake control: Closing threshold delay 0 ms general U16 1 P -
0x2820:013
(P712.13)
Holding brake control: Holding load rampme 0 ms general U16 1 P -
0x2820:015
(P712.15)
Holding brake control: Brake status - (Read only) general U8 1 - -
0x2822:004
(P327.04)
Axis commands: Idenfy motor data (energized) 0 general U8 1 - -
0x2822:005
(P327.05)
Axis commands: Calibrate motor data (non-ener-
gized)
0 general U8 1 - -
0x2822:019 Axis commands: Calculate Imax controller parame-
ter
0 general U8 1 - -
0x2824
(P200.00)
Control selecon Flexible I/O conguraon
[0]
general U8 1 P -
0x2826 Time-out for error response 6.0 s general U16 10 P -
0x2827
(P198.00)
Currently loaded parameter sengs - (Read only) general U8 1 - -
0x2829
(P732.00)
Automac storage in the memory module Inhibit [0] general U8 1 P -
0x282A:001
(P126.01)
Status words: Cause of disable - (Read only) general U32 1 O -
0x282A:002
(P126.02)
Status words: Cause of quick stop - (Read only) general U16 1 O -
0x282A:003
(P126.03)
Status words: Cause of stop - (Read only) general U16 1 O -
0x282A:004 Status words: Extended status word - (Read only) general U16 1 O t
0x282A:005
(P126.05)
Status words: Device status - (Read only) general U8 1 O t
* Default seng depending on the size. Firmware version 05.00.00.00
Appendix
Parameter aribute list
