C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
ā 40 ā
Protocol-based
VLAN
175
Protocol to
Group
Creates a protocol group, specifying supported protocols 175
Group to VLAN Maps a protocol group to a VLAN for specified ports 177
IP Subnet-based
VLAN
Maps traffic for a specified IP subnet to a VLAN 178
Voice VLAN 179
Configuration Configures global settings, including status, voice VLAN ID,
VLAN aging time, and traffic priority; also configures port
settings, including the way in which a port is added to the
Voice VLAN, and blocking non-VoIP addresses
180
OUI Maps the OUI in the source MAC address of ingress packets
to the VoIP device manufacturer
182
QoS 183
Port Classification Configures default traffic class, drop priority, user priority,
drop eligible indicator, classification mode for tagged frames,
and DSCP-based QoS classification
184
Port Policing Controls the bandwidth provided for frames entering the
ingress queue of specified ports.
185
Port Scheduler Provides overview of QoS Egress Port Schedulers, including
the queue mode and weight; also configures egress queue
mode, queue shaper (rate and access to excess bandwidth),
and port shaper
186
Port Shaping Provides overview of QoS Egress Port Shapers, including the
rate for each queue and port; also configures egress queue
mode, queue shaper (rate and access to excess bandwidth),
and port shaper
188
Port Tag
Remarking
Provides overview of QoS Egress Port Tag Remarking; also
sets the remarking mode (classified PCP/DEI values, default
PCP/DEI values, or mapped versions of QoS class and drop
priority)
189
Port DSCP Configures ingress translation and classification settings and
egress re-writing of DSCP values
192
DSCP-Based QoS Configures DSCP-based QoS ingress classification settings 193
DSCP Translation Configures DSCP translation for ingress traffic or DSCP re-
mapping for egress traffic
194
DSCP
Classification
Maps DSCP values to a QoS class and drop precedence level 195
QoS Control List Configures QoS policies for handling ingress packets based
on Ethernet type, VLAN ID, TCP/UDP port, DSCP, ToS, or
VLAN priority tag
196
Storm Control Sets limits for broadcast, multicast, and unknown unicast
traffic
200
WRED Configures minimum threshold and drop probabilities for
queues 0-5 using Weighted Random Early Detection
201
Congestion
Management
Forwards traffic only if the destination port is not congested 203
Mirroring & RSPAN
2
Sets source and target ports for local or remote mirroring 204
UPnP Enables UPNP and defines timeout values 210
Table 4: Main Menu (Continued)
Menu Description Page
