C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 41 –
sFlow Samples traffic flows, and forwards data to designated
collector
211
Monitor 215
System 215
Information Displays basic system description, switch’s MAC address,
system time, and software version
215
CPU Load Displays graphic scale of CPU utilization 216
Log Displays logged messages based on severity 217
Detailed Log Displays detailed information on each logged message 219
Ports 219
State Displays a graphic image of the front panel indicating active
port connections
219
Traffic Overview Shows basic Ethernet port statistics 220
QoS Statistics Shows the number of packets entering and leaving the
egress queues
220
QCL Status Shows the status of QoS Control List entries 221
Detailed Statistics Shows detailed Ethernet port statistics 222
Security 225
Access
Management
Statistics
Displays the number of packets used to manage the switch
via HTTP, HTTPS, and SNMP, Telnet, and SSH
225
Network
Port Security
Switch Shows information about MAC address learning for each
port, including the software module requesting port security
services, the service state, the current number of learned
addresses, and the maximum number of secure addresses
allowed
226
Port Shows the entries authorized by port security services,
including MAC address, VLAN ID, the service state, time
added to table, age, and hold state
228
NAS Shows global and port settings for IEEE 802.1X
Switch Shows port status for authentication services, including
802.1X security state, last source address used for
authentication, and last ID
229
Port Displays authentication statistics for the selected port –
either for 802.1X protocol or for the remote authentication
server depending on the authentication method
230
ACL Status Shows the status for different security modules which use
ACL filtering, including ingress port, frame type, and
forwarding action
234
DHCP Dynamic Host Configuration Protocol
Snooping
Statistics
Shows statistics for various types of DHCP protocol packets 236
Relay
Statistics
Displays server and client statistics for packets affected by
the relay information policy
237
Table 4: Main Menu (Continued)
Menu Description Page
