C HAPTER 3 | Using the Web Interface
Navigating the Web Browser Interface
– 42 –
ARP Inspection Displays entries in the ARP inspection table, sorted first by
port, then VLAN ID, MAC address, and finally IP address
238
IP Source Guard Displays entries in the IP Source Guard table, sorted first by
port, then VLAN ID, MAC address, and finally IP address
239
AAA Authentication, Authorization and Accounting 240
RADIUS
Overview
Displays status of configured RADIUS authentication and
accounting servers
240
RADIUS Details Displays the traffic and status associated with each
configured RADIUS server
241
Switch
RMON Remote Monitoring 245
Statistics Shows sampled data for each entry in the statistics group 245
History Shows sampled data for each entry in the history group 246
Alarm Shows all configured alarms 247
Event Shows all logged events 248
LACP Link Aggregation Control Protocol 249
System Status Displays administration key and associated local ports for
each partner
249
Port Status Displays administration key, LAG ID, partner ID, and partner
ports for each local port
249
Port Statistics Displays statistics for LACP protocol messages 250
Spanning Tree 251
Bridge Status Displays global bridge and port settings for STA 251
Port Status Displays STA role, state, and uptime for each port 254
Port Statistics Displays statistics for RSTP, STP and TCN protocol packets 255
MVR Multicast VLAN Registration 256
Statistics Shows statistics for IGMP protocol messages used by MVR 256
MVR Channel
Groups
Shows information about the interfaces associated with
multicast groups assigned to the MVR VLAN
257
MVR SFM
Information
Displays MVR Source-Filtered Multicast information including
group, filtering mode (include or exclude), source address,
and type (allow or deny)
258
IPMC IP Multicast
IGMP Snooping 259
Status Displays statistics related to IGMP packets passed upstream
to the IGMP Querier or downstream to multicast clients
259
Group
Information
Displays active IGMP groups 260
IPv4 SFM
Information
Displays IGMP Source-Filtered Multicast information
including group, filtering mode (include or exclude), source
address, and type (allow or deny)
261
MLD Snooping Multicast Listener Discovery Snooping 262
Status Displays MLD querier status and protocol statistics 262
Table 4: Main Menu (Continued)
Menu Description Page
