C HAPTER 3 | Using the Web Interface
Navigating the Web Browser Interface
– 43 –
Group
Information
Displays active MLD groups 263
IPv6 SFM
Information
Displays MLD Source-Filtered Multicast information including
group, filtering mode (include or exclude), source address,
and type (allow or deny)
264
LLDP Link Layer Discovery Protocol 265
Neighbors Displays LLDP information about a remote device connected
to a port on this switch
265
LLDP-MED
Neighbors
3
Displays information about a remote device connected to a
port on this switch which is advertising LLDP-MED TLVs,
including network connectivity device, endpoint device,
capabilities, application type, and policy
266
EEE Displays Energy Efficient Ethernet information advertised
through LLDP messages
268
Port Statistics Displays statistics for all connected remote devices, and
statistics for LLDP protocol packets crossing each port
270
MAC Table Displays dynamic and static address entries associated with
the CPU and each port
271
VLANs Virtual LANs 272
VLAN Membership Shows the current port members for all VLANs configured by
a selected software module
272
VLAN Port Shows the VLAN attributes of port members for all VLANs
configured by a selected software module which uses VLAN
management, including PVID, VLAN aware, ingress filtering,
frame type, egress filtering, and PVID
273
VCL VLAN Control List
MAC-based VLAN Displays MAC address to VLAN map entries 275
sFlow Displays information on sampled traffic, including the owner,
receiver address, remaining sampling time, and statistics for
UDP control packets and sampled traffic
276
Diagnostics 279
Ping Tests specified path using IPv4 ping 279
Ping6 Tests specified path using IPv6 ping 279
VeriPHY Performs cable diagnostics for all ports or selected port to
diagnose any cable faults (short, open etc.) and report the
cable length
281
Maintenance 283
Restart Device Restarts the switch 283
Factory Defaults Restores factory default settings 284
Software
Upload Updates software on the switch with a file specified on the
management station
284
Image Select Displays information about the active and alternate (backup)
firmware images in the switch, and allows you to revert to
the alternate image
285
Table 4: Main Menu (Continued)
Menu Description Page
