Lexmark MS610 Series Service Manual

Option tray separator/passthrough motor service check
Action Yes No
Step 1
a Remove the option tray insert.
b Check the separator roll assembly gear under the tray base for the
following:
• Gear tooth breakage
• Freedom of rotation
Does it move freely, and is it free of wear or damage?
Go to step 2. Replace the tray.
Step 2
Check the cable J10 on the option tray controller card.
Is it properly connected and free of damage?
Go to step 3. Replace the tray.
Step 3
Check the separator roll assembly for wear or damage.
Is it free of wear or damage?
Contact the next level
of support.
Replace the separator
roll assembly. See
“Separator roll
assembly removal” on
page 248.
Option tray ACM motor service check
Action Yes No
Step 1
Check the cable J11 on the option tray controller card.
Is it properly connected?
Go to step 2. Reseat the cable.
Step 2
a Remove the option tray insert and bypass the tray present sensor.
b POR into the Diagnostics Menu and perform a feed test:
Diagnostics Menu > Feed Test > choose an option tray
c Check the ACM for proper operation.
Does the ACM freely rotate three times before displaying a jam message?
Go to step 3. Replace the ACM
assembly. See “ACM
assembly removal” on
page 250.
Step 3
Is the ACM gear free of wear or damage?
Contact the next level
of support.
Replace the ACM
assembly. See “ACM
assembly removal” on
page 250.
4514-630, -635, -636
Diagnostic information
107

Lexmark MS610 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 50 ppm
Print Resolution	1200 x 1200 dpi
Processor Speed	800 MHz
Standard Memory	256 MB
Maximum Memory	1280 MB
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	Ethernet
Input Capacity	Up to 650 pages
Duplex Printing	Yes
