6 Remove the four screws (A) securing the duplex.

A

Note: The duplex link (B) is part of the FRU.

B

Duplex sensor and input sensor removal

1 Remove the left cover. See “Left cover removal” on page 166.

2 Remove the right cover. See “Right cover removal” on page 178.

4514-630, -635, -636

Repair information

227
