Lexmark MS610 Series Service Manual

A
Front input guide removal
1 Remove the right cover. See “Right cover removal” on page 178.
2 Remove the front door. See “Front door removal” on page 215.
3 Remove the MPF pick roller cover. See “MPF pick roller cover removal” on page 213.
4 Remove the MPF pick roller. See “MPF pick roller removal” on page 213.
5 Remove the jam access cover. See “Jam access cover removal” on page 214.
6 Disconnect cable JMPF1 from the controller board.
7 Remove the four screws (A).
A
8 Push and hold the cam restraint to release the MPF shaft.
4514-630, -635, -636
Repair information
219

Lexmark MS610 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 50 ppm
Print Resolution	1200 x 1200 dpi
Processor Speed	800 MHz
Standard Memory	256 MB
Maximum Memory	1280 MB
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	Ethernet
Input Capacity	Up to 650 pages
Duplex Printing	Yes
