7 Remove the screw (B) from the right front mount, and route the cables through the slot.

8 Remove the five screws (C) securing the control panel to the front door.

UICC removals

UICC removal (MS510dn and MS610dn)

1 Remove the right cover. See “Right cover removal” on page 178.

2 Remove the nameplate. See “Nameplate removals” on page 199.

4514-630, -635, -636

Repair information

205
