Lexmark MS610 Series Service Manual

Assembly 2: Electronics 1
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8081 1 1 Laser scanning unit “Laser scanning unit (LSU) removal”
on page 246
2 40X8343 1 1 Fuser, 100 V “Fuser removal” on page 244
2 40X8023 1 1 Fuser, 110 V “Fuser removal” on page 244
2 40X8024 1 1 Fuser, 220 V “Fuser removal” on page 244
3 40X8050 1 1 Narrow media/bin full sensor “Narrow media/bin full sensor
removal” on page 241
4 40X8276 1 1 Cooling fan (MS510dn, MS610dn) “Cooling fan removals” on page
180
4 40X8274 1 1 Cooling fan (MS610de) “Cooling fan removals” on page
180
5 40X8029 1 1 Controller board (MS510dn) “Controller board removals” on
page 184
5 40X8030 1 1 Controller board (MS610dn) “Controller board removals” on
page 184
6 40X8388 1 1 Controller board (MS610de) “Controller board removals” on
page 184
7 40X7592 1 1 Tray present sensor “Tray present sensor removal” on
page 179
8 40X8280 1 1 Front input guide “Front input guide removal” on
page 219
9 40X8300 1 1 MPF solenoid “MPF solenoid removal” on
page 169
10 40X8301 1 1 Reverse solenoid “Reverse solenoid removal” on
page 174
11 40X8285 1 1 Control panel assembly (MS610de) “Control panel assembly removals”
on page 201
12 40X8292 1 1 Control panel assembly (MS510dn) “Control panel assembly removals”
on page 201
12 40X8284 1 1 Control panel assembly (MS610dn) “Control panel assembly removals”
on page 201
4514-630, -635, -636
Parts catalog
268

Lexmark MS610 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 50 ppm
Print Resolution	1200 x 1200 dpi
Processor Speed	800 MHz
Standard Memory	256 MB
Maximum Memory	1280 MB
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	Ethernet
Input Capacity	Up to 650 pages
Duplex Printing	Yes
