MS610de exterior locations

Front view

1

2

3

5

6

7

8

4

Part name

1 Control panel

2 Paper stop

3 Standard bin

4 Front door release button

5 Controller board access door

6 100‑sheet multipurpose feeder

7 Standard tray

8 Optional 250‑ or 550‑sheet tray

4514-630, -635, -636

Component locations

255
