Operating clearances

5

1

2

3

4

1

2

3

4

5

1 Right 30 cm (12 in.)

2Front51 cm (20 in.)

3Left20 cm (8 in.)

4Rear20 cm (8 in.)

5Top30 cm (12 in.)

Allow additional clearance around the printer for adding the optional input trays.

Acoustics

All measurements are made in accordance with ISO 7779 and conform with ISO 9296.

4514-630, -635, -636

Appendix A: Printer specifications

280
