Lexmark MS610 Series Service Manual

Service menus
Understanding the control panel and menus (MS510dn and
MS610dn)
Using the printer control panel
1
2
3
4
5
6
7
8
9
10
11
12
13
Use the To
1 Display View the printer status and messages.
Set up and operate the printer.
2 Left arrow button Scroll to the left.
3 Select button Select menu options.
Save settings.
4 Up arrow button Scroll up.
5 Right arrow button Scroll to the right.
6 Keypad Enter numbers, letters, or symbols.
7 Sleep button Enable Sleep mode or Hibernate mode.
The following actions wake the printer from Sleep mode:
• Pressing any hard button
• Opening a tray or the front door
• Sending a print job from the computer
• Performing a power‑on reset using the main power switch
• Attaching a device in the USB port
8 USB port Connect a flash drive to the printer.
Notes:
• Only the front USB port supports flash drives.
• This feature is available only in select printer models.
9 Stop or cancel button Stop all printer activities.
4514-630, -635, -636
Service menus
117

Lexmark MS610 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 50 ppm
Print Resolution	1200 x 1200 dpi
Processor Speed	800 MHz
Standard Memory	256 MB
Maximum Memory	1280 MB
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	Ethernet
Input Capacity	Up to 650 pages
Duplex Printing	Yes
