Lexmark MS610 Series Service Manual

5 Remove the two screws (A), and then remove the control panel USB port.
A
Speaker and control panel USB port removal (MS610de)
1 Remove the right cover. See “Right cover removal” on page 178.
2 Remove the nameplate. See “Nameplate removals” on page 199.
3 Remove the bezel. See “Bezel removals” on page 197.
4 Remove the control panel assembly. See “Control panel assembly removals” on page 201.
5 Remove the three screws (A), and then remove the speaker and control panel USB port.
A
4514-630, -635, -636
Repair information
209

Lexmark MS610 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 50 ppm
Print Resolution	1200 x 1200 dpi
Processor Speed	800 MHz
Standard Memory	256 MB
Maximum Memory	1280 MB
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	Ethernet
Input Capacity	Up to 650 pages
Duplex Printing	Yes
