Repair information
Removal precautions
CAUTION—SHOCK HAZARD: For personal safety and to prevent damage to the printer, remove the power cord
from the electrical outlet before you connect or disconnect any cable, electronic board, or assembly. Disconnect
any connections between the printer and the PCs/peripherals.
Data security notice
This printer contains various types of memory that are capable of storing device and network settings, information
from embedded solutions, and user data. The types of memory, along with the types of data stored by each, are
described below.
Volatile memory—This device utilizes standard Random Access Memory (RAM) to temporarily buffer user data
during simple print and copy jobs.
Non-volatile memory—This device may utilize two forms of non-volatile memory: EEPROM and NAND (flash
memory). Both types are used to store the operating system, device settings, network information, scanner and
bookmark settings, and embedded solutions.
Hard disk memory—Some devices have a hard disk drive installed. The printer hard disk is designed for device-
specific functionality and cannot be used for long term storage for data that is not print-related. The hard disk does
not provide the capability for users to extract information, create folders, create disk or network file shares, or
transfer FTP information directly from a client device. The hard disk can retain buffered user data from complex
print jobs, as well as form data and font data.
To erase volatile memory, turn off the printer.
To erase non-volatile memory, see the menu item under “Configuration menu” on page 137 pertaining to this.
To erase the printer hard disk, see the menu item under “Configuration menu” on page 137 pertaining to this.
The printer control panel and RIP/controller board contain NVRAM. After removing the old part, it must be returned
to your next level of support.
Handling ESDsensitive parts
Many electronic products use parts that are known to be sensitive to electrostatic discharge (ESD). To prevent damage
to ESD-sensitive parts, use the following instructions in addition to all the usual precautions, such as turning off power
before removing logic boards:
Keep the ESD-sensitive part in its original shipping container (a special “ESD bag”) until you are ready to install the
part into the machine.
Make the least-possible movements with your body to prevent an increase of static electricity from clothing fibers,
carpets, and furniture.
Put the ESD wrist strap on your wrist. Connect the wrist band to the system ground point. This discharges any static
electricity in your body to the machine.
Hold the ESD-sensitive part by its edge connector shroud (cover); do not touch its pins. If you are removing a
pluggable module, use the correct tool.
4514-630, -635, -636
