Lexmark MS610 Series Service Manual

3 Remove the four screws (A), and then remove the jam access cover.
A
Front door removal
Note: This is not a FRU.
1 Remove the right cover. See “Right cover removal” on page 178.
2 Disconnect the following cables from the controller board:
For MS510dn and MS610dn:
• JUICC1
• JCVR1
• If applicable, JUSBF1
For MS610de:
• JUICC
• JCVR1
• JAUD1
• J43
4514-630, -635, -636
Repair information
215

Lexmark MS610 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 50 ppm
Print Resolution	1200 x 1200 dpi
Processor Speed	800 MHz
Standard Memory	256 MB
Maximum Memory	1280 MB
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	Ethernet
Input Capacity	Up to 650 pages
Duplex Printing	Yes
