h Secure the cable to the holder.

MPF gearbox removal

1 Remove the left cover. See “Left cover removal” on page 166.

2 Remove the main drive gearbox. See “Main drive gearbox removal” on page 167.

3 Remove the front door. See “Front door removal” on page 215.

4 Disconnect the spring from the printer (A).

4514-630, -635, -636

Repair information

171
