Lexmark MS610 Series Service Manual

Bottom removals
Power supply removals
Power supply removal
1 Remove the left cover. See “Left cover removal” on page 166.
2 Remove the rear door and cover. See “Rear door and cover removal” on page 240.
3 Disconnect the cable (A) from the rear, and disconnect the cable (B) from the left side.
AB
4 Position the printer so that it sits on its right side.
5 Remove the three screws (C), and then remove the right tray guide.
C
4514-630, -635, -636
Repair information
223

Lexmark MS610 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 50 ppm
Print Resolution	1200 x 1200 dpi
Processor Speed	800 MHz
Standard Memory	256 MB
Maximum Memory	1280 MB
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	Ethernet
Input Capacity	Up to 650 pages
Duplex Printing	Yes
