Lexmark MS610 Series Service Manual

8 Remove the E-clip (E), and then remove the MPF sector gear (F).
EF
Reverse solenoid removal
1 Remove the right cover. See “Right cover removal” on page 178.
2 Remove the left cover. See “Left cover removal” on page 166.
3 Remove the rear door and cover. See “Rear door and cover removal” on page 240.
4 Remove the top cover. See “Top cover removal” on page 245.
5 Remove the cooling fan. See “Cooling fan removals” on page 180.
6 Disconnect cable JDRSOL1 from the controller board.
4514-630, -635, -636
Repair information
174

Lexmark MS610 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 50 ppm
Print Resolution	1200 x 1200 dpi
Processor Speed	800 MHz
Standard Memory	256 MB
Maximum Memory	1280 MB
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	Ethernet
Input Capacity	Up to 650 pages
Duplex Printing	Yes
