Rear side removals

Dust cover removal

1 Press the latches on each side of the dust cover.

2 Remove the dust cover.

2

1

Rear door and cover removal

1 Position the printer so that it sits on either its left or right side.

2 Open the rear door at an angle of 45 degrees.

4514-630, -635, -636

Repair information

240
