Lexmark MS610 Series Service Manual

Action Yes No
Step 6
a Remove the main drive gearbox.
b Check the gears for wear or damage.
c Check the main drive motor for rotation.
Are the gears free of wear or damage and does the main drive motor
rotate?
Go to step 7. Replace the main drive
gearbox. See “Main
drive gearbox
removal” on page
167.
Step 7
Replace the controller board.
Does the error remain?
Problem is solved. Contact the next level
of support.
Printer/cartridge mismatch service check
Action Yes No
Step 1
a Make sure the toner cartridge smart chip contact cable JARW1 is
properly connected to the controller board.
b Make sure the toner cartridge smart chip contact is free of debris.
c Check the toner cartridge smart chip contact for damaged pins.
Is it free of damage?
Go to step 2. Replace the toner
cartridge smart chip
contact. See “Toner
cartridge smart chip
contact removal” on
page 188.
Step 2
Check if the firmware level matches the serial number.
Do they match?
Replace the controller
board. See “Controller
board removals” on
page 184.
Reflash the firmware.
4514-630, -635, -636
Diagnostic information
86

Lexmark MS610 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 50 ppm
Print Resolution	1200 x 1200 dpi
Processor Speed	800 MHz
Standard Memory	256 MB
Maximum Memory	1280 MB
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	Ethernet
Input Capacity	Up to 650 pages
Duplex Printing	Yes
