Lexmark MS610 Series Service Manual

Assembly 4: Frame
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X5364 1 1 Transfer roll “Transfer roll removal” on page 193
2 40X8298 1 1 Redrive assembly (MS510dn) “Redrive assembly removal” on
page 243
2 40X8437 1 1 Redrive assembly (MS611dn) “Redrive assembly removal” on
page 243
2 40X8438 1 1 Redrive assembly (MS611de) “Redrive assembly removal” on
page 243
3 40X8299 1 1 Front mounts “Left front mount removal” on
page 190
“Right front mount removal” on
page 191
4 40X8084 1 1 Pick/Lift motor gearbox “Pick/Lift motor gearbox removal” on
page 239
5 40X8275 1 1 Duplex assembly “Duplex removal” on page 226
6 40X8297 2 1 Pick tire N/A
7 40X8261 1 1 ACM assembly “ACM assembly removal” on
page 233
8 40X8295 2 2 MPF pick roller and separator pad “MPF pick roller removal” on
page 213
and
“Separator pad removal” on page
221
9 40X8279 1 1 Jam access cover “Jam access cover removal” on
page 214
10 40X8278 1 1 MPF gearbox “MPF gearbox removal” on page 171
11 40X8277 1 1 Duplex gear assembly “Duplex gear assembly removal” on
page 176
12 40X8083 1 1 Cartridge gearbox “Cartridge gearbox removal” on
page 175
13 40X8085 1 1 Main drive gearbox “Main drive gearbox removal” on
page 167
NS 40X8394 1 1 Screw kit N/A
4514-630, -635, -636
Parts catalog
272

Lexmark MS610 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 50 ppm
Print Resolution	1200 x 1200 dpi
Processor Speed	800 MHz
Standard Memory	256 MB
Maximum Memory	1280 MB
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	Ethernet
Input Capacity	Up to 650 pages
Duplex Printing	Yes
