12-18
RLC-4 V1.79 Copyright © 1998 Link Communications Inc. 9/18/98
107: Recall Analog Lines in Alarm
This command lists all of the ports in high alarm, then all of the ports in low alarm. It is helpful
when trying to find out whether you have set the alarm points correctly.
<107>
Parameters:
- 107 is the default command name.
CW Response:
- If the response reads 'H' 'C' then the High analog alarms are clear
- If the response reads 'L' 'C' then the Low analog alarms are clear
- The response will list all channels in alarm:
- 'H' XXXX Where 'XXXX' are the channels in high alarm
- 'L' XXXX Where 'XXXX' are the channels in low alarm
108: Recall Analog Line Configuration
This command recalls all kinds of information about an analog line's conversion, resolution,
calibration, alarm points, hysteresis, alarm enabled/disabled status, etc. It intended to aid in setting
up the analog subsystem, not as a user command.
<108> l
Parameters:
- 108 is the default command name.
- L is the analog input line number (1..4)
Description of the CW response:
"A #" - which analog input referred to (1..4)
"### V" - the lower calibration point
"### V" - the upper calibration point
"C ###" - how many units the calibration changes the reading
"L ###" - the low alarm point
"H ###" - the high alarm point
"Y ###" - the amount of hysteresis
"L N/F" - whether alarm is on or off
"H N/F" - whether alarm is on or off
