16-4
RLC-4 V1.79 Copyright © 1998 Link Communications Inc. 9/18/98
039: Recall the Ports in the Current Audio Routing Variable
This command allows you to determine what ports audio is being sent out of without having a radio
tuned to each of the transmitters. It sends a list of numbers which represent the ports that are
included in the audio routing variable at the time it is executed (see Appendix A for more
information about audio routing variables).
<039>
Example:
You want to know what transmitters are hearing the courtesy beep that is generated when
port 3's receiver unkeys. Solution: append this command to the end of the courtesy beep macro
(161) for port three so it will send the numbers of the ports that just heard the courtesy beep:
<056> 161 039 <unkey>
Note:
To delete command 039 from the courtesy beep macro when you are tired of hearing it, use
command 059 and you will not have to delete the whole macro and program it again.
