Link Communications RLC-4 User Manual

2-9
RLC-4 V1.79 Copyright © 1998 Link Communications Inc. 9/18/98
Example:
You want to change the receiver and DTMF mode to COR and PL (mode 3) on port 2.
Note that you don’t need to specify the DTMF mode if it is the same as the receiver mode:
<005> 2 3 <unkey> or <005> 2 3 3
Response:
CW Response "2 CAP CAP" (CAP is for Cor And PL)
Example:
You want to allow carrier access to a repeater on port 1, but you want to require PL to
enter DTMF commands.
<005> 1 3 1
Response:
CW Response "1 CAP COR"
006: Recall Receiver and DTMF Decoder Conditions
This command allows you to recall the conditions set with command 005.
<006> p Recall a port’s access mode
Parameters:
- 006 is the default command name.
- ‘p’ is the port number (1..4)
