J-3
RLC-4 V1.79 Copyright © 1998 Link Communications Inc. 9/18/98
5 - AUX #2 SWITCH, CURRENTLY NOT DEFINED
I/O Board
+))))))))))))))))))))))))))))))))))))))))))))))))))))))))))))))))))))))))))))),
* *
* *
* 1 2 3 4 5 6 7 8 ON *
/)), +0000000000000000, *
* * A S2 *.-.-.-.-.-.-.-.-* | *
* * N .))))))))))))))))- OFF *
* * A ANALOG VOLTAGE *
* * L DIVIDER SWITCH *
* * O 1 2 3 4 5 6 7 8 ON *
* * G +0000000000000000, *
* * S1 *.-.-.-.-.-.-.-.-* | *
* * & .))))))))))))))))- OFF *
* * ANALOG TEMPERATURE *
* * I POWER SWITCH *
* * / *
* * O *
/))- *
* *
* *
* +)))))))))))))))))))))), *
* * USER PORT #1 AND #2 * *
* * * *
.))))))))))))))))2))))))))))))))))))))))2)))))))))))))))))))))))))))))))))))))-
S1 - Analog Temperature Power Switch
- This switch allows you to externally power the LM335 Temperature Sensor
-- When the switch is on, +10v is feed to the external sensor
S2 - Analog Voltage Divider Switch
- This switch allows you to directly read 0.00v - 25.0 volts
-- When the switch is on, the voltage divider in circuit
