14-8
RLC-4 V1.79 Copyright © 1998 Link Communications Inc. 9/18/98
The default setup for the RLC-Icom is to have connector 1 plugged into the 140..160 Mhz
module, connector 2 plugged into the 220 Mhz module and connector 3 plugged into the
430..440 Mhz module. As an example, the following commands will enter those settings
again:
Command 139 110 <unkey>
Command 139 215 <unkey>
Command 139 320 <unkey>
Second, you must tell each band module what size of offset to use when you select a plus
or minus offset with Commands 142 or 143. The setup codes follow:
SS (the setup code) Description
30 100 Khz Offset
35 500 Khz Offset
40 600 Khz Offset
45 1 Mhz Offset
50 1.6 Mhz Offset
55 1.7 Mhz Offset
60 5 Mhz Offset
65 12 Mhz Offset
70 20 Mhz Offset
Example:
To select a 100 Khz offset for the 140..160 Mhz module that is plugged into connector 1,
enter Command 139 130 D or unkey.
Setup codes 75 and 80 are reserved for special offset memories, which are not yet
supported.
