© 2011 LPKF AG HB V2.0/Dez-11 75
5. Click on [motor on/off].
➨ The drilling spindle rotates and the dust extraction is activated.
6. Click on [Lift head up/down ].
➨ The mill/drill head is lowered and the corresponding drilling hole is created.
After this process the mill/drill head returns to the rest position.
7. Click on [Motor on/off].
➨ The drilling spindle stops and the dust extraction is deactivated.
8. Repeat steps 3 to 6 if you wish to create further drilling holes.
♦ The drilling hole is created.
